ECO-WORTHY SL3500 Stackable Power Station with 4×200W Portable Solar Panels | 5120 Wh Capacity | Emergency Backup | Portable & Expandable Power & Capacity
ECO-WORTHY SL3500 Stackable Power Station with 4×200W Portable Solar Panels | 5120 Wh Capacity | Emergency Backup | Portable & Expandable Power & Capacity
ECO-WORTHY SL3500 Stackable Power Station
SL3500 Power Station
| Model： SL3500 | Output voltage waveform: Pure sine wave |
| Permitted parallel number: 2 | Rated output power: 3500W |
| AC rated input voltage: 110/120Vac | Peak power: 6000W |
| AC Frequency: 50Hz/60Hz | Battery voltage range: 40-60Vdc |
| AC max. Bypass overload current： 40A | Maximum PV input power: 4400W |
| Maximum PV input current: 50A |
Maximum MPPT tracking efficiency: 99.9% |
|
Operating temperature range: -10℃~60℃ |
Dimension（L*W*D）：485*398*145mm/19.09*15.66*5.7inch |
|
Weight：13.1kg/28.88lbs |
|
200W Portable Solar Panels
|
Module Type
: 210 |
Maximum Power - Pmax(W):
200W±3%
|
|
Maximum Power Voltage - Vmp(V):19.4
|
Maximum Power Current - Imp(A):
10.32
|
| Open Circuit Voltage - Voc(V):
23.3
|
Short Circuit Current - Isc(A):
10.94
|
| Module Efficiency STC(%):
23%
|
Testing Condition(STC):
All technical data at STC: AM=1.5
Irradiance=1000w/m² Tc=25℃
|
| Dimension（Unfolded）:
200.8*66.6*0.4cm/
79.06*26.22*0.16inch
|
Dimension(Folded):
53.2*66.6*5cm/
20.94*26.22*1.97inch
|
|
Solar panel cable:
1.5 meters, MC4 to DC8020,DC7909,XT60
|
Weight:10kg |
Original: $2,199.00
-70%$2,199.00
$659.70More Images
ECO-WORTHY SL3500 Stackable Power Station with 4×200W Portable Solar Panels | 5120 Wh Capacity | Emergency Backup | Portable & Expandable Power & Capacity
ECO-WORTHY SL3500 Stackable Power Station
SL3500 Power Station
| Model： SL3500 | Output voltage waveform: Pure sine wave |
| Permitted parallel number: 2 | Rated output power: 3500W |
| AC rated input voltage: 110/120Vac | Peak power: 6000W |
| AC Frequency: 50Hz/60Hz | Battery voltage range: 40-60Vdc |
| AC max. Bypass overload current： 40A | Maximum PV input power: 4400W |
| Maximum PV input current: 50A |
Maximum MPPT tracking efficiency: 99.9% |
|
Operating temperature range: -10℃~60℃ |
Dimension（L*W*D）：485*398*145mm/19.09*15.66*5.7inch |
|
Weight：13.1kg/28.88lbs |
|
200W Portable Solar Panels
|
Module Type
: 210 |
Maximum Power - Pmax(W):
200W±3%
|
|
Maximum Power Voltage - Vmp(V):19.4
|
Maximum Power Current - Imp(A):
10.32
|
| Open Circuit Voltage - Voc(V):
23.3
|
Short Circuit Current - Isc(A):
10.94
|
| Module Efficiency STC(%):
23%
|
Testing Condition(STC):
All technical data at STC: AM=1.5
Irradiance=1000w/m² Tc=25℃
|
| Dimension（Unfolded）:
200.8*66.6*0.4cm/
79.06*26.22*0.16inch
|
Dimension(Folded):
53.2*66.6*5cm/
20.94*26.22*1.97inch
|
|
Solar panel cable:
1.5 meters, MC4 to DC8020,DC7909,XT60
|
Weight:10kg |
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
ECO-WORTHY SL3500 Stackable Power Station
SL3500 Power Station
| Model： SL3500 | Output voltage waveform: Pure sine wave |
| Permitted parallel number: 2 | Rated output power: 3500W |
| AC rated input voltage: 110/120Vac | Peak power: 6000W |
| AC Frequency: 50Hz/60Hz | Battery voltage range: 40-60Vdc |
| AC max. Bypass overload current： 40A | Maximum PV input power: 4400W |
| Maximum PV input current: 50A |
Maximum MPPT tracking efficiency: 99.9% |
|
Operating temperature range: -10℃~60℃ |
Dimension（L*W*D）：485*398*145mm/19.09*15.66*5.7inch |
|
Weight：13.1kg/28.88lbs |
|
200W Portable Solar Panels
|
Module Type
: 210 |
Maximum Power - Pmax(W):
200W±3%
|
|
Maximum Power Voltage - Vmp(V):19.4
|
Maximum Power Current - Imp(A):
10.32
|
| Open Circuit Voltage - Voc(V):
23.3
|
Short Circuit Current - Isc(A):
10.94
|
| Module Efficiency STC(%):
23%
|
Testing Condition(STC):
All technical data at STC: AM=1.5
Irradiance=1000w/m² Tc=25℃
|
| Dimension（Unfolded）:
200.8*66.6*0.4cm/
79.06*26.22*0.16inch
|
Dimension(Folded):
53.2*66.6*5cm/
20.94*26.22*1.97inch
|
|
Solar panel cable:
1.5 meters, MC4 to DC8020,DC7909,XT60
|
Weight:10kg |
